The BIOTRAP® Range

Available in Standard & Made-to-Measure Sizes

An under sink BIOTRAP with the lid removed

BIOTRAP-US

Under Sink

Materials: 304 stainless steel.
Inlet/Outlet Location: See spec sheet.
Capacity: 100 litres.
Installation: 2 hours approx.
Lead-time: In stock.
Suitable for: Indoors. For under sinks and combi-ovens.

A below ground BIOTRAP with a flat top lid removed

BIOTRAP-IBG

Indoor Below Ground

Materials: 304 stainless steel.
Inlet/Outlet Location: Optional.
Capacity: From 300 litres to any size.
Installation: 3-8 hours.
Lead-time: 35-40 working days.
Suitable for: Indoors. Both above and below ground.

A below ground BIOTRAP with a flat top lid removed

BIOTRAP-OBG

Outdoor Below Ground

Materials: 304 stainless steel.
Inlet/Outlet Location: Optional.
Capacity: From 100 litres to any size.
Installation: 3-8 hours.
Lead-time: 35-40 working days.
Suitable for: Outdoors. Below ground only.
Covers: Load bearing covers for cars/vans/trucks.

An above ground BIOTRAP with two flat top lids removed

BIOTRAP-AG

Above Ground

Materials: 304 stainless steel.
Inlet/Outlet Location: Optional.
Capacity: From 100 litres to any size.
Installation: 3-8 hours.
Lead-time: 35-40 working days.
Suitable for: Indoors and outdoors. Above ground only.

A below ground BIOTRAP with a recessed timber lid removed

BIOTRAP-IBG(R)

Indoor Below Ground with Recessed Lid

Materials: 304 stainless steel.
Inlet/Outlet Location: Optional.
Capacity: From 300 litres to any size.
Installation: 3-8 hours.
Lead-time: 35-40 working days.
Suitable for: Indoors. Below ground only.

A below ground BIOTRAP with a recessed tiled lid removed

BIOTRAP-OBG(R)

Outdoor Below Ground with Recessed Lid

Materials: 304 stainless steel.
Inlet/Outlet Location: Optional.
Capacity: From 100 litres to any size.
Installation: 3-8 hours.
Lead-time: 35-40 working days.
Suitable for: Outdoors. Below ground only.

Technical Specifications & Installation Details

Correct Sizing – A Legal Requirement

Non-slip flat top lids are made from 304-grade
stainless steel and are secured to the base unit with M20 threaded bolts. The compression seals ensure a 100% airtight seal so they are perfectly suited for outdoor (under- ground) dining locations or areas of high foot traffic, such as forecourts, picnic spaces. car parks, footpaths, etc.

BIOTRAP® with Pedestrian Lids

A drawing of pedestrians walking over a recessed BIOTRAP lid

Standard flat top lids will accommodate pedestrian traffic or light goods trolleys and pallet trucks. Car lids are also available. The lids are easily removed to provide unrestricted access to all areas of the greasetrap. This ensures the unit can be thoroughly cleaned and washed down in compliance with I.S. EN 1825 parts 1 & 2.

BIOTRAP® with Car Lids

A drawing of a car driving over a recessed BIOTRAP lid

All our outdoor and indoor below ground BIOTRAPS can be supplied with either an independent or integrated Load Class D lids. Recessed lids are also available to accept asphalt, concrete, tiles, or timber. The OBG range is available in standard and non-standard sizes that range from Ns1 to NS50.

BIOTRAP® with HGV Lids

A drawing of a HGV driving over a recessed BIOTRAP lid

The Below Ground Range

Recessed Lids to Accept Any Floor Type.

Recessed lids are the ideal way to minimise the visual impact of a greasetrap in an area of high foot traffic or where a continuous tarmac, concrete, cobble-lock, tile, or timber effect needs to be achieved. Each lid is secured to the base unit with x4 threaded bolts which are located in each corner.

Recessed Lids for Timber Floors

A below ground BIOTRAP with a recessed timber lid removed

Our recessed lid model will accommodate pedestrian traffic or light goods trolleys and pallet trucks. HGV and car lids are also available. The lid design ensures the unit can be thoroughly cleaned and washed down in compliance with I.S. EN 1825 parts 1 & 2.

Recessed Lids for Tile Floors

A below ground BIOTRAP with a recessed tiled lid removed

The recessed model can be supplied with independent or integrated lids. The compression seals ensure a 100% airtight seal so they are perfectly suited for any indoor or outdoor (underground) location. As with all our BIOTRAPS, the recessed model comes with variable inlet/outlet locations.

Recessed Lids for Asphalt

A below ground BIOTRAP with a recessed asphalt lid removed
